Capabilities
- Thicknesses cut: thin gauge sheets thru 8" plate are easily cut to tight tolerances.
- Tolerances: part tolerance of +/- .030 is standard; tolerances of +/- .005 can be provided
- Part Consistency: at 60% cut speed, part consistency tolerances are +/- .001
- Table Size: 120" X 240"
- Edge Finish: there is no heat affected zone with waterjet cutting; the edge finish is 250 rms or better cut at 60% cut speed
- Taper: taper is virtually eliminated by Dynamic waterjet cutting technology
